 Product characteristicsInductive sensorRectangular, plasticsTerminalsSensing range 20 mm; [nf] non-flush mountable Electrical dataElectrical designAC/DCOperating voltage [V]20...250 AC/DCProtection classIIReverse polarity protectionno OutputsOutput functionnormally open / closed programmableVoltage drop [V]< 6.5 AC / < 6 DCMinimum load current [mA]5Leakage current [mA]< 2.5 (250 V AC) / < 1.3 (110 V AC) / < 0.8 (24 V DC)Current rating- Current rating (continuous) [mA]250 AC / 100 DC; 350 AC (...50 °C)- Current rating (peak) [mA]î: 2.2 A (20 ms / 0.5 Hz)Short-circuit proofnoOverload protectionnoSwitching frequency [Hz]20 AC / 55 DC RangeSensing range [mm]20Real sensing range (Sr) [mm]20 ± 10 %Operating distance [mm]0...16.2 Accuracy / deviationsCorrection factorsmild steel = 1 / stainless steel approx. 0.7 / brass approx. 0.4 / Al approx. 0.3 / Cu approx. 0.2Hysteresis [% of Sr]1...15Switch-point drift [% of Sr]-10...10 EnvironmentAmbient temperature [°C]-25...80ProtectionIP 65 Tests / approvalsEMC

MTTF [Years]604 Mechanical dataMountingnon-flush mountableHousing materialsPPEWeight [kg]0.183 Displays / operating elementsOutput status indication LEDyellow Electrical connectionConnectionterminals up to 2.5 mm²; cable diameter 7...13 mm, cable gland M20 x 1.5Wiring

 RemarksRemarks

Pack quantity [piece]1ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen  —  We reserve the right to make technical alterations without prior notice.  —  GB  —  IM0010  —  06.03.2003
